Perforated brake disc Masuma LH, BD-1532DL
About product
Applicability
OEM
LX450D
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| 4.5L 1VD-FTV Diesel. VDJ201L. EUR | 2015.09-2022.12 | 4.5L DIESEL 1VD-FTV CRI (272 PS / 200 kW) Four-wheel drive (4WD). Left Hand Drive |
LX570
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| 5.7L 3UR-FE. URJ201L. EUR | 2015.09-2021.12 | 5.7L GASOLINE 3UR-FE EFI (367 PS / 285 kW) Four-wheel drive (4WD). Left Hand Drive |
LAND CRUISER
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| 4.5L 1VD-FTV Diesel. VDJ200L. EUR | 2015.08-2021.06 | 4.5L DIESEL 1VD-FTV (249 PS / 183 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. URJ202L. EUR | 2015.08-2021.06 | 4.6L GASOLINE 1UR-FE EFI (309 PS / 227 kW) Four-wheel drive (4WD). Left Hand Drive |
SEQUOIA
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| 4.7L 2UZ-FE. UCK65L. USA | 2007.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (273 PS / 201 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.7L 2UZ-FE. UCK60L. USA | 2007.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (273 PS / 201 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FE. USK65L. USA | 2007.11-2017.08 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK60L. USA | 2007.11-2017.08 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FBE. USK65L. USA | 2008.08-2017.08 | 5.7L 3UR-FBE EFI (383 PS / 282 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK65L. USA | 2009.04-2012.08 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK60L. USA | 2009.04-2012.08 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
TUNDRA
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| 4.7L 2UZ-FE. UCK55L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.7L 2UZ-FE. UCK56L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.7L 2UZ-FE. UCK56L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.7L 2UZ-FE. UCK57L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.7L 2UZ-FE. UCK50L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Rear-wheel drive. Left Hand Drive |
| 4.7L 2UZ-FE. UCK51L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Rear-wheel drive. Left Hand Drive |
| 4.7L 2UZ-FE. UCK51L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Rear-wheel drive. Left Hand Drive |
| 4.7L 2UZ-FE. UCK52L. USA | 2006.11-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Rear-wheel drive. Left Hand Drive |
| 4.0L 1GR-FE. GSK50L. USA | 2006.11-2014.09 | 4.0L GASOLINE 1GR-FE EFI (270 PS / 199 kW) Rear-wheel drive. Left Hand Drive |
| 4.0L 1GR-FE. GSK51L. USA | 2006.11-2014.09 | 4.0L GASOLINE 1GR-FE EFI (270 PS / 199 kW) Rear-wheel drive. Left Hand Drive |
| 4.0L 1GR-FE. GSK51L. USA | 2006.11-2014.09 | 4.0L GASOLINE 1GR-FE EFI (270 PS / 199 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FE. USK50L. USA | 2007.01-2010.05 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FE. USK55L. USA | 2007.01-2013.08 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK56L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK56L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK57L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK51L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FE. USK51L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive |
| 5.7L 3UR-FE. USK52L. USA | 2007.01-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive |
| 4.7L 2UZ-FE. UCK56L. USA | 2007.03-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Four-wheel drive (4WD). Left Hand Drive Crew Max |
| 4.7L 2UZ-FE. UCK51L. USA | 2007.03-2009.04 | 4.7L GASOLINE 2UZ-FE EFI (276 PS / 203 kW) Rear-wheel drive. Left Hand Drive Crew Max |
| 5.7L 3UR-FE. USK56L. USA | 2007.03-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Four-wheel drive (4WD). Left Hand Drive Crew Max |
| 5.7L 3UR-FE. USK51L. USA | 2007.03-2021.12 | 5.7L GASOLINE 3UR-FE EFI (381 PS / 280 kW) Rear-wheel drive. Left Hand Drive Crew Max |
| 5.7L 3UR-FBE. USK55L. USA | 2008.08-2013.08 | 5.7L 3UR-FBE EFI (357 PS / 263 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK57L. USA | 2008.08-2019.07 | 5.7L 3UR-FBE EFI (357 PS / 263 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK56L. USA | 2008.08-2019.07 | 5.7L 3UR-FBE EFI (357 PS / 267 kW) Four-wheel drive (4WD). Left Hand Drive Crew Max |
| 5.7L 3UR-FBE. USK56L. USA | 2008.08-2019.07 | 5.7L 3UR-FBE EFI (378 PS / 278 kW) Four-wheel drive (4WD). Left Hand Drive |
| 5.7L 3UR-FE. USK56L. USA | 2008.08-2019.07 | 5.7L 3UR-FBE EFI (378 PS / 278 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK56L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK56L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK57L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK51L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
| 4.6L 1UR-FE. UPK52L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
| 4.6L 1UR-FE. UPK55L. USA | 2009.04-2010.05 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
| 4.6L 1UR-FE. UPK50L. USA | 2009.04-2013.08 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
| 4.6L 1UR-FE. UPK56L. USA | 2009.04-2019.07 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive |
| 4.6L 1UR-FE. UPK56L. USA | 2009.04-2019.07 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Four-wheel drive (4WD). Left Hand Drive Crew Max |
| 4.6L 1UR-FE. UPK51L. USA | 2009.04-2019.07 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive |
| 4.6L 1UR-FE. UPK51L. USA | 2009.04-2019.07 | 4.6L GASOLINE 1UR-FE EFI (310 PS / 228 kW) Rear-wheel drive. Left Hand Drive Crew Max |
Specifications:
D, Diameter: 354 mm
H, Height: 83.2 mm
H1, Brake disc thickness: 32 mm
d, Central hole diameter: 112 mm
L, PCD: 150 mm
N, Number of mounting holes: 5
H, Height: 83.2 mm
H1, Brake disc thickness: 32 mm
d, Central hole diameter: 112 mm
L, PCD: 150 mm
N, Number of mounting holes: 5
Masuma perforated brake discs are engineered to maintain optimal operating temperature for brake pads, keep the rotor surface clean, and dry quickly when driving through rain or standing water. This ensures consistent, predictable braking performance under various conditions.
The precision-drilled perforations enhance self-cleaning by removing friction dust, abrasive particles, and moisture from the braking surface. They also promote active air circulation across the rotor, efficiently dissipating excess heat. This helps prevent overheating of both the discs and pads, even during extended or high-load braking.
Manufactured from high-strength cast iron with special alloying additives, Masuma brake discs retain their structural integrity despite perforation. Each disc undergoes multi-stage geometric inspection, dynamic balancing, and is rated to withstand temperatures up to 650 °C.
About Masuma
Masuma is a global brand specializing in auto parts, components, and consumables. The company focuses on producing high-wear replacement parts for post-warranty maintenance of Asian and European vehicles.
Masuma’s strategy is to deliver the best balance of reliability and cost, making quality parts accessible to more drivers and service professionals. All products are developed according to Masuma’s own specifications and manufactured under strict quality control by Masuma Auto Spare Parts Co., LTD (Tokyo, Japan) at multiple state-of-the-art factories across East Asia.
