Perforated brake disc Masuma LH, BD-1516DL
This spare part fits on cars TOYOTA
LAND CRUISER
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| HDJ100L | 2000.09-2003.02 | 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive |
| HDJ101K | 2000.09-2003.02 | 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive |
| UZJ100L | 2000.09-2003.02 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive |
| UZJ100W | 2000.09-2003.02 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive |
| HDJ100L | 2003.02-2005.12 | 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive |
| HDJ101K | 2003.02-2005.12 | 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive |
| UZJ100L | 2003.02-2005.12 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive |
| UZJ100W | 2003.02-2005.12 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive |
| HDJ100L | 2005.12-2007.08 | 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive |
| HDJ101K | 2005.12-2007.08 | 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive |
| UZJ100L | 2005.12-2007.08 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive |
| UZJ100L | 2005.12-2007.08 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive |
| UZJ100W | 2005.12-2007.08 | 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive |
LAND CRUISER 100
| Body/Volume | Installation period | Car configuration |
|---|---|---|
| UZJ100L | 2000.09-2003.02 | 4.7L GASOLINE 2UZFE EFI (230 PS / 169 kW) Four-wheel drive (4WD). Left Hand Drive |
Specifications:
H, Height: 102.4 mm
H1, Brake disc thickness: 18 mm
L, PCD: 150 mm
N, Number of mounting holes: 5
d, Central hole diameter: 110 mm
Masuma perforated brake discs are engineered to maintain optimal operating temperature for brake pads, keep the rotor surface clean, and dry quickly when driving through rain or standing water. This ensures consistent, predictable braking performance under various conditions.
The precision-drilled perforations enhance self-cleaning by removing friction dust, abrasive particles, and moisture from the braking surface. They also promote active air circulation across the rotor, efficiently dissipating excess heat. This helps prevent overheating of both the discs and pads, even during extended or high-load braking.
Manufactured from high-strength cast iron with special alloying additives, Masuma brake discs retain their structural integrity despite perforation. Each disc undergoes multi-stage geometric inspection, dynamic balancing, and is rated to withstand temperatures up to 650 °C.
