Brake disk Masuma, BD-1516

Article: BD-1516
About product
Applicability
OEM

This spare part fits on cars TOYOTA

Body/Volume Installation period Car configuration
HDJ100L 2000.09-2003.02 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive
HDJ101K 2000.09-2003.02 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive
UZJ100L 2000.09-2003.02 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive
UZJ100W 2000.09-2003.02 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive
HDJ100L 2003.02-2005.12 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive
HDJ101K 2003.02-2005.12 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive
UZJ100L 2003.02-2005.12 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive
UZJ100W 2003.02-2005.12 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive
HDJ100L 2005.12-2007.08 4.2L DIESEL 1HDFTE (204 PS / 150 kW) Four-wheel drive (4WD). Left Hand Drive
HDJ101K 2005.12-2007.08 4.2L DIESEL 1HDFTE (205 PS / 151 kW) Four-wheel drive (4WD). Right Hand Drive
UZJ100L 2005.12-2007.08 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive
UZJ100L 2005.12-2007.08 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Left Hand Drive
UZJ100W 2005.12-2007.08 4.7L GASOLINE 2UZFE EFI (235 PS / 173 kW) Four-wheel drive (4WD). Right Hand Drive
Body/Volume Installation period Car configuration
UZJ100L 2000.09-2003.02 4.7L GASOLINE 2UZFE EFI (230 PS / 169 kW) Four-wheel drive (4WD). Left Hand Drive

Specifications:

D, Diameter: 329.2 mm
H, Height: 102.4 mm
H1, Brake disc thickness: 18 mm
L, PCD: 150 mm
N, Number of mounting holes: 5
d, Central hole diameter: 110 mm

Masuma brake discs are produced using high-strength cast iron with spherical graphite. The castings are produced accurately with the tolerances of just several microns, it guarantees the correct disc geometry with no vibrations during the operation.

Masuma produces two types of brake discs: ventilated and non-ventilated. The working surface of almost all the models has non-directional coating. This ensures the fast and uniform lapping after installation.

About Masuma

Masuma is a global brand specializing in auto parts, components, and consumables. The company focuses on producing high-wear replacement parts for post-warranty maintenance of Asian and European vehicles.

Masuma’s strategy is to deliver the best balance of reliability and cost, making quality parts accessible to more drivers and service professionals. All products are developed according to Masuma’s own specifications and manufactured under strict quality control by Masuma Auto Spare Parts Co., LTD (Tokyo, Japan) at multiple state-of-the-art factories across East Asia.
